lidoom

DOOM port for Project Lighthouse.

Building

To build the project, run

cargo build

Optionally, you can build it with a GUI. This requires SDL2, see these instructions. If you are running macOS and have installed SDL2 via Homebrew, you can source the following script to add the Homebrew-provided SDL2 to your library path:

source ./buildenv.sh

Then build the project with the gui flag:

cargo build --features gui

[!TIP] If you are developing with rust-analyzer in VSCode, add the following to your .vscode/settings.json to enable language support in the GUI module:

{
  "rust-analyzer.cargo.features": ["gui"]
}

Running

Make sure to have the following environment variables set or in a .env file in the working directory:

LIGHTHOUSE_USER=<your user>
LIGHTHOUSE_TOKEN=<your token>

Additionally, make sure that your working directory contains a DOOM WAD (e.g. DOOM1.WAD), which you need to obtain externally, then run

cargo run

Optionally, use --features gui here too.

Input

The game can take input both via the Lighthouse frontend (LUNA) and via the SDL GUI. When using the Lighthouse frontend, make sure to leave "Legacy Mode" unchecked.

Controls

The controls are mapped in a relatively standard fashion, applying the modern conventions for FPS-style games:

• Mouse:
  • Movement controls camera (though only if pointer is locked, which can be done by clicking the window to lock and pressing escape to unlock)
  • Left button fires
• Keyboard:
  • WASD controls movement
  • Arrow keys control camera
  • Shift enables sprint
  • Space fires
  • Ctrl uses an item
• Gamepad:
  • Left stick/d-pad control movement
  • Right stick controls camera
  • Menu button opens the escape menu
  • Cluster left button (Xbox: "X", PS: Square) enables sprint
  • Cluster bottom button (Xbox: "A", PS: Cross) presses enter
  • Cluster right button (Xbox: "B", PS: Circle) uses an item

All of these mappings are implemented in mapper.rs.

Architecture

Internally, lidoom uses a number of threads and virtual threads (Tokio tasks) to communicate. This architecture allows for robust bridging between blocking contexts (e.g. the SDL GUI on the main thread or DOOM, which runs on its own thread) and Tokio's async tasks (for the communication with the lighthouse server). Graphically, the architecture can be visualized as follows:

flowchart LR
  Lighthouse[Lighthouse server]
  subgraph lidoom
    subgraph Tokio threads
      Controller
      Mapper
      Updater
    end
    subgraph DOOM thread
      DOOM
    end
    subgraph Main thread
      GUI
    end
    Controller -- ControllerMessage --> Mapper
    GUI -- ControllerMessage --> Mapper
    Mapper -- MapperMessage --> DOOM
    DOOM -- UpdaterMessage --> Updater
    DOOM -- GUIMessage --> GUI
  end
  Lighthouse --> Controller
  Updater --> Lighthouse
